MK7 Extruder Drive Gear

A high quality MK7 style hobbed gear for your extruder. We offer these in 2 styles, with different heights and filament groove positions

 Option 1

• 13mm tall, ~10mm from centerline of filament groove to the farthest edge of the gear
• Sized for 1.75mm or 3mm filament
• 5mm bore
• 12mm overall diameter
• Set screw included

 Option 2

• 11mm tall, ~7.5mm from centerline of filament grove to the farthest edge of the gear
• Sized for 1.75mm filament only
• 5mm bore
• ~12.65 (.5inch) overall diameter
• Set screw included
